Fluke 376 1000A/1000V True-RMS AC/DC Clamp Meters

The Fluke 376 Clamp Meter offers improved performance perfect for a wide range of current measurement situations. With true-rms ac voltage and current measurements, the Fluke 376 can read up to 1000 V and 1000 A in both ac and dc modes. Additionally, the Fluke 376 includes the new iFlex flexible current probe expanding the measurement range to 2500 A ac while providing increased display flexibility, ability to measure around awkward sized conductors and improved wire access. The Fluke 376 is the direct replacement for the Fluke 337 Clamp Meter..

Specifications
Function Range Resolution Accuracy
AC Current via jaw 999.9 A 0.1A 2 % ± 5 digits
AC current via iFlex 2500 A 0.1A 3 % ± 5 digits
DC current 999.9 A 0.1A 2 % ± 5 digits
AC Voltage 1000 V 0.1V 1.5 % ± 5 digits
DC Voltage 1000 V 0.1mV 1 % ± 5 digits
Resistance 60,000 Ω 0.1Ω 1 % ± 5 digits
Frequency 500 Hz 0.1Hz 0.5 % ± 5 digits
Capacitance 1000 µF 1µF 1 % ± 4 digits
True-RMS Included
Continuity Included
Hold Included
Backlight Included
Min/Max/Avg Included
Inrush Included
Low pass filter Included
Wire capacity 750 MCM or 2-500 MCM
Safety rating CAT III 1000 V, CAT IV 600 V
